Series 2 Mini Brush Cutter, Open Front
A 42-inch open-front cutter for mini skid steers that need better reach into overgrowth while staying compact, maneuverable, and easy to run on lighter hydraulic packages.
Product Overview
The Blue Diamond Series 2 Mini Brush Cutter, Open Front is built for compact clearing work where an open deck gives operators better access into brush and heavier grass. Its direct-drive spindle, three double-edged blades, bi-directional blade rotation, and lifetime spindle warranty make it a practical fit for trail work, overgrowth cleanup, and property maintenance on mini skid steers.
Key Features
- Open-front deck configuration
- 42-inch cutting width
- 4-inch cutting capacity
- Direct drive with lifetime spindle warranty
- Three double-edged blades with bi-directional rotation
- Maximum operating pressure: 3000 PSI
Configuration
| Part No. | Configuration | Flow Range | Weight |
|---|---|---|---|
| 303728 | 42 in. / 80cc / Open Front | 11-20 GPM | 600 lbs no mount |
Machine Compatibility
Designed for mini skid steer applications using 11-20 GPM auxiliary hydraulic flow. Blue Diamond offers this family in Mini Universal, Bobcat MT, and Avant mount configurations, so final fitment should be matched to the exact machine, mount style, and expected cutting conditions.
Additional Specifications
| Cutting Width | 42 in. |
| Overall Width | 50 in. |
| Overall Length | 50 in. |
| Overall Height | 21 in. |
| Cutting Height | 3.5 in. |
| Operating Pressure | 3000 PSI max |
Shipping & Lead Time
Ships by freight. Region Equipment can confirm current availability, freight cost, and lead time when your quote is prepared.
Warranty
Backed by Blue Diamond's 12-month limited warranty for this product family, plus a lifetime spindle warranty.
Installation & Service
Confirm mount style, hydraulic flow, and material type before ordering so the cutter is matched correctly to the machine and the work.
