Wallenstein · Skidding Winch

Product details

Overview

The FX85RS uses tractor PTO power to retrieve logs with remote winch control.

  • PTO-driven mechanical winch with a dry-disc clutch.
  • Synthetic rope supplied for log retrieval.
  • Two choker chains and two sliders support log connection.

Applications

  • Forestry & Mulching
  • Land Clearing

Model & setup

Model / SKU
FX85RS
Equipment type
Tractor
Mounting system
Cat I

Your quote includes this model. We confirm the required mounting, connections and options for your application.

Specifications

Performance & operation

Cable Type
Synthetic Rope
Pulling Capacity
8500 lbs (3855 kg)
Winch Type
Mechanical, Dry Disc Clutch
Line Speed
96 - 238 ft/min (29 - 72 m/min)

Power & connections

Engine HP Range
30 - 55
Required Hydraulic Flow
1 - 2 gpm (4 - 8 lpm)
PTO Input Speed
540 rpm
Mounting System
Cat I

Dimensions & construction

Cable Length
200' (60 m)
Cable Diameter
7/16" (11 mm)
PTO Height
16" (41 cm)
Total Weight
470 lb (213 kg)
Dimensions (LxWxH)
27" x 40" x 76" (69 cm x 102 cm x 193 cm)

Included equipment

Choker Chains
2

Confirm host-machine capacity, mounting arrangement and applicable hydraulic or PTO requirements before ordering. Listed mounting options require configuration confirmation.

Manuals & documents

Download ManualManufacturer Support

Configuration, installation & support

Configuration & Installation
  • Confirm hitch fit, tractor stability and PTO shaft length before setup. Use the supplied guarding and model-specific winching procedures.
  • The remote-control circuit requires 1–2 GPM hydraulics. Match the control-system manual to the installed remote generation.
  • Connect synthetic rope through an approved choker; do not wrap the winch rope directly around a log.
Warranty
  • Manufacturer limited warranty: five years for consumer use or two years for commercial/rental use, subject to original-purchaser eligibility, maintenance and exclusions.
