At a glance
- Engine
- Honda GX390
- Receiver
- Two 4-gallon horizontal tanks
- Air delivery
- 17.9 ACFM at 175 PSIG
Champion RV-Series Compressor and Generator HGRV7-LPH-G
Built for
Professional Shop Air
Support
System Sizing & Installation
Coverage
Nationwide
Regular price
$5,044.55
Financing available.
Learn more
Final fitment, freight, lead time, and order details are confirmed by Region Equipment before completion.
Product overview
Compressed air and power for mobile work.
The Champion HGRV7-LPH-G combines a Honda GX390 engine, RV15A compressor pump and generator in one package. Twin 4-gallon receivers, electric start and a lifting hook support mobile service work.
Package design
- Compressor and generator in one package.
- Twin 4-gallon horizontal receivers.
- Electric start and lifting hook.
Plan your mobile setup
- Provide a suitable outdoor operating location.
- Review air demand and generator load together.
- Plan for mounting and the required starting battery.
Selected packageHGRV7-LPH-G
Stock no. CC1153480
Engine-driven compressor & generator
Compressor & air delivery
- Model
- HGRV7-LPH-G
- Compressor pump
- RV15A
- Compression stages
- Two-stage
- Air delivery at rated pressure
- 17.9 ACFM at 175 PSIG
- Receivers
- Two 4-gallon horizontal tanks
Engine & generator
- Engine
- Honda GX390
- Maximum generator output
- 4,000 W maximum
- Continuous generator output
- 3,500 W with compressor off-load
- Starting
- Electric start
- Starting battery
- Not included
Product documents
Champion engine-driven product information Download engine-driven performance sheet (includes HGRV7-LPH-G) Download engine-driven brochure (includes compressor/generator)Use the installation and service manual supplied for your exact package.
Generator continuous output is rated with the compressor off-load. Confirm simultaneous operating limits for your application.
Combined air & power
The engine drives the compressor and generator in one package.
Generator rating
Maximum output is 4,000 W. The 3,500 W continuous rating applies with the compressor off-load.
Mobile package
Twin horizontal receivers and a lifting hook are included.
Electric start
Electric starting is provided; the starting battery is not included.
Operating location
Follow the engine-driven package manual for outdoor operation, exhaust clearance, fuel handling and mounting.
Electrical loads
Confirm generator loads and simultaneous operating limits before connecting equipment.
Starting battery
Confirm the specified battery and cables before commissioning; the battery is not included.
Service support
Use the package and engine manuals for maintenance. Region Equipment can help coordinate service and parts.
Shipping & lead time
Freight, unloading arrangements and delivery timing are confirmed for the selected package and destination. Installation and commissioning can be coordinated with Region Equipment.
