Challenger CLHM-MR heavy-duty wheel lift system

Challenger CLHM-MR Series 20,000–40,000 lb Heavy-Duty Wheel Lift System

SKU: CLHM-MR20 Category: Shop Support Equipment
Built for Professional Service Facilities
Support Installation Available
Coverage Nationwide
$10,944.19
Financing available. Learn more
CALL NOW (866) 608-5565

Final fitment, freight, lead time, and order details are confirmed by Region Equipment before completion.

Lift overview

Built around your service bay.

The Challenger CLHM-MR Series is a portable, compressed-air wheel lift system for low-ceiling heavy-duty service bays. Its built-in support-stand function provides open access below the vehicle.

At a glance

Rated capacity
20,000, 30,000, or 40,000 lb rated capacity per pair, by model
Lift design
Heavy-Duty Wheel Lift System
Configurations
3 available
View full specifications

Built for your workflow

  • Fleet and commercial vehicle service
  • Confirm the selected model’s wheelbase, dimensions and capacity.

Plan your bay

  • Confirm per-column and complete-system ratings, tire fit, axle loads and approved column combinations.
  • Use a level, load-rated surface and follow the exact manual for synchronization, charging and lifting procedures.
  • Linked operating manual covers MR20/MR30; obtain the MR40-specific documentation before supplying that configuration.
Installation details
Selected modelCLHM-MR20

Model CLHM-MR20

Selected configuration

Model
CLHM-MR20
Configuration
20K Lbs./Set Wheel Lift (Set Of 2) - Each Used To Lift Front Or Rear Axel Of The Vehicle

Manufacturer wheel-lift brochure · selected model

Lifting capacity per set
20,000 lb
Lift height
Floor level to 30 in.
Power
Compressed air
Maximum air pressure
160 PSI
Stroke
30 in.
Minimum wheel diameter with adapters
16 in.
Minimum wheel diameter without adapters
19 in.
Maximum wheel diameter
44 in.
Overall width
42.25 in.
Overall depth
43.25 in.
Overall height
58.75–88.75 in.
Shipping weight
1,200 lb

Family specifications & equipment

Capacity
20,000, 30,000, or 40,000 lb rated capacity per pair, by model
Dimensions & reach
30 in. maximum lift height
Design & equipment
Air-pressure requirements vary by model; confirm the selected unit’s manual
Design & equipment
Wheel and tire fit varies by model and adapter configuration
Design & equipment
Published shipping weights: 1,200 lb (MR20), 1,500 lb (MR30), 1,965 lb (MR40)

Manuals & specifications

Installation, operation & maintenance manual Download spec sheet Manufacturer product page

Use the manual for the selected control package and model revision.

Family specifications describe the published equipment. Options may change dimensions, power requirements, certification and included equipment. Confirm the exact selected model and supplied documentation before ordering or installation. Wheel-diameter limits follow Challenger’s model-specific wheel-lift brochure because the website table duplicates the MR40 column label. Confirm final fit against the supplied manual.
