Heavy Duty Excavator Brush Cutter
A rugged excavator brush cutter family built for operators who need controlled reach, dependable direct-drive performance, and multiple width and motor choices for clearing work that demands more than a light-duty deck.
Product Overview
The Blue Diamond Heavy Duty Excavator Brush Cutter is designed for contractors and land-clearing crews who want excavator-mounted cutting performance with more reach and more control in uneven terrain. Greaseable direct drive, AR400 blades, a reinforced deck, and multiple width and motor combinations make this family a practical fit for vegetation management, roadside work, and selective clearing.
Key Features
- 36-inch, 42-inch, and 50-inch cutting widths
- 80cc, 100cc, 125cc, and 160cc motor configurations depending on model
- 4-inch cutting capacity
- Greaseable direct-drive system
- Three double-sided AR400 blades
- 3/4-inch blade carrier
- Reinforced deck with skid plate protection
Model Options
| Part No. | Model | Flow Range | Host Machine Size | Weight |
|---|---|---|---|---|
| 103600 | 36 in. Heavy Duty / 80cc | 13-28 GPM | 6,000-15,000 lbs | 551 lbs |
| 103610 | 36 in. Heavy Duty / 100cc | 29-36 GPM | 6,000-15,000 lbs | 544 lbs |
| 103650 | 42 in. Heavy Duty / 80cc | 13-24 GPM | 7,300-19,000 lbs | 630 lbs |
| 103660 | 42 in. Heavy Duty / 100cc | 25-31 GPM | 7,300-19,000 lbs | 662 lbs |
| 103709 | 50 in. Heavy Duty / 80cc | 13-22 GPM | 12,000-19,000 lbs | 939 lbs |
| 103712 | 50 in. Heavy Duty / 100cc | 23-28 GPM | 12,000-19,000 lbs | 934 lbs |
| 103713 | 50 in. Heavy Duty / 125cc | 28-33 GPM | 12,000-19,000 lbs | 941 lbs |
| 103714 | 50 in. Heavy Duty / 160cc | 34-41 GPM | 12,000-19,000 lbs | 965 lbs |
Machine Compatibility
Designed for excavator applications and best matched by carrier weight, hydraulic flow, and the selected motor package. This family spans multiple carrier sizes, so final fitment should always be confirmed against the exact machine, coupler setup, and intended cutting conditions.
Additional Specifications
| Cutting Capacity | 4 in. |
| Blade Configuration | 3 double-sided AR400 blades |
| Blade Carrier | 3/4 in. thick |
| Hydraulic Pressure | 3,200 PSI maximum |
| Case Drain | Not required |
Shipping & Lead Time
Ships by freight. Region Equipment can confirm availability, freight cost, and current lead time when your quote is prepared.
Warranty
Backed by Blue Diamond's 12-month limited warranty for this product family.
Installation & Service
Before ordering, confirm carrier weight, hydraulic flow, bracket setup, and the specific model configuration that best matches the machine and the work.
