60" Severe Duty Excavator Brush Cutter
A severe-duty excavator cutter family built for operators who need 60-inch coverage, heavier motor options, and the ability to keep clearing when the material gets thicker and the workload gets tougher.
Product Overview
The Blue Diamond 60" Severe Duty Excavator Brush Cutter is built for contractors who need more cutter authority, more motor choices, and a platform that can keep working in demanding clearing conditions. A reinforced deck, heavy blade carrier, enclosed motor protection, and multiple piston-motor options make it a strong fit for vegetation management, site work, and serious land clearing.
Key Features
- 60-inch cutting width
- Up to 6-inch cutting capacity
- 150cc, 200cc, and 250cc piston motor options
- 1/2-inch reinforced deck
- Three 3/4-inch double-sided blades
- 1-inch serrated blade carrier
- Enclosed motor protection
- Case drain required
Model Configuration
| Part No. | Model | Required Flow | Host Machine Size |
|---|---|---|---|
| 303860 | 60 in. Excavator Cutter / 150cc | 24-34 GPM | 38,000-60,000 lbs |
| 303865 | 60 in. Excavator Cutter / 200cc | 35-45 GPM | 38,000-60,000 lbs |
| 303867 | 60 in. Excavator Cutter / 250cc | 45-55 GPM | 38,000-60,000 lbs |
Machine Compatibility
Designed for excavator applications in the listed 38,000-60,000 lb range and best matched by hydraulic flow, motor option, and carrier setup. Because this family spans a broad carrier range, final fitment should always be confirmed against the exact machine, coupler configuration, and working conditions.
Additional Specifications
| Cutting Width | 60 in. |
| Cutting Capacity | 6 in. |
| Deck Construction | 1/2 in. reinforced deck |
| Blade Carrier | 1 in. serrated blade carrier |
| Case Drain | Required |
Shipping & Lead Time
Ships by freight. Region Equipment can confirm availability, freight cost, and current lead time when your quote is prepared.
Warranty
Backed by Blue Diamond's 12-month limited warranty for this product family.
Installation & Service
Before ordering, confirm case drain provision, hydraulic flow, motor selection, and bracket setup so the cutter is matched correctly to the carrier and the work.
